• Paint, solid
• Bumper, front, chrome, with Gray lower
• Air dam, Gray
• Wheel flares, front only
• Grille, Gray surround
• Headlamps, dual halogen composite, includes flash-to-pass feature and automatic lamp control
• Daytime running lamps, includes automatic exterior lamp control
• Lamps, amber roof marker
• Mirrors, outside rearview, foldaway, manual, Black, below eye-line, adjustable heads
• Glass, Solar-Ray light tinted, all windows
• Wipers, intermittent, front, wet-arm with pulse washers

• Seat trim, vinyl
• Seats, front 40/20/40 split-bench, 3-passenger, driver and passenger manual reclining with outboard head restraints
• Seat, rear bench, folding, 3-passenger (includes child seat top tether anchor) (Standard with Extended Cab Models only.)
• Floor covering, rubberized vinyl, Black
• Steering wheel, steel sleeve, includes theft-deterrent locking feature
• Theft-deterrent system, PASSlock II
• Warning tones, headlamp on, key-in-ignition, driver and passenger seat belt reminder, turn signal on
• Windows, rear quarter swing-out (Standard with Extended Cab Models only.)
• Air conditioning, dual-zone, manual, individual climate settings for driver and right front passenger
• Sound system, ETR AM/FM stereo, includes seek-and-scan and digital clock
• Sound system feature, 4-speakers
• Cupholders, front (Also includes rear cupholders on Extended Cab Models.)
• Cigarette lighter, on instrument panel
• Power outlets, auxiliary, covered, 2 dash-mounted, 12-volt
• Mirror, inside rearview, manual day/night
• Coat hook, driver side (Also includes passenger side coat hook on Extended Cab Models.)
• Visors, padded, Shale-colored, driver and passenger side with cloth trim, extenders, pocket on driver side and vanity mirror on passenger side
• Assist handle, front passenger (Also includes rear outboard passenger assist handle on Extended Cab Models.)
• Lighting, dome lamp, reading, courtesy, illuminated entry feature, backlit instrument panel switches and door handle-activated illuminated entry

• Brakes, 4-wheel antilock, 4-wheel disc
• Air bags, frontal, driver and right front passenger, includes passenger side deactivation switch (Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information.)
• Daytime running lamps, includes automatic exterior lamp control

ENGINE, DURAMAX 6600 TURBO DIESEL V8

• (with Manual Transmissions 300 HP [223.8 kW] @ 3000 rpm
• 520 lb.-ft. [702.0 N-m] @ 1600 rpm) (with Automatic Transmissions 310 HP [231.2 KW] @ 3100 rpm
• 590 lb.-ft. [796.5 N-m] @ 1600 rpm) (Includes (TQ3) Battery
• heavy-duty dual 770 cold-cranking amps
• (K05) Engine block heater
• and (K47) Air cleaner
• high capacity.)

• 40/20/40 Front Split-Bench Seat
• ETR AM/FM Stereo w/CD Player
• Solar-Ray Deep Tinted Glass
• Electronic Cruise Control w/Set & Resume Speed
• 2 Front Frame-Mounted Recovery Hooks
• Engine Block Heater
• Heavy-Duty Handling/Trailering Suspension Package
• Dual Heavy-Duty 770 CCA Batteries
• Dual rear wheels
• Front beverage holders
• Variably intermittent wipers
• Tilt steering wheel
• Power steering
• Passenger vanity mirror
• Passenger door bin
• Passenger cancellable airbag
• Fully automatic headlights
• Front wheel independent suspension
• Front dual zone A/C
• Front anti-roll bar
• Dual front impact airbags
• Driver door bin
• Bumpers: chrome
• AM/FM radio
• ABS brakes
• Voltmeter
• Tachometer
• Air Conditioning
• 4-Wheel Disc Brakes

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 770
• Cold Cranking Amps @ 0° F (Primary): 600
• Cold Cranking Amps @ 0° F (2nd): 770
• Maximum Alternator Capacity (amps): 105
• Cooling System
• Total Cooling System Capacity (qts): 15.5
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4670
• Gross Axle Wt Rating - Rear (lbs): 8550
• Curb Weight - Front (lbs): 3221
• Curb Weight - Rear (lbs): 2469
• Gross Vehicle Weight Rating Cap (lbs): 11,400
• Gross Combined Wt Rating (lbs): 23500
• Gross Combined Wt Rating (lbs): 16000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): N/A
• Dead Weight Hitch - Max Tongue Wt. (lbs): N/A
• Wt Distributing Hitch - Max Trailer Wt. (lbs): N/A
• Wt Distributing Hitch - Max Tongue Wt. (lbs): N/A
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): N/A
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): N/A
• Suspension
• Suspension Type - Front: Indep Torsion Bar
• Suspension Type - Rear: 3-Stage Spring
• Spring Capacity - Front (lbs): 4800
• Spring Capacity - Rear (lbs): 8600
• Axle Type - Front: Independent
• Axle Type - Rear: Full Floating
• Axle Capacity - Front (lbs): 4800
• Axle Capacity - Rear (lbs): 9200
• Axle Ratio (:1) - Rear: 4.10
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.25
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.8 x 1.5
• Rear Brake Rotor Diam x Thickness (in): 12.8 x 1.2
• Tires
• Front Tire Order Code: XYK
• Rear Tire Order Code: XYK
• Front Tire Size: LT215/85R16D
• Rear Tire Size: LT215/85R16D
• Front Tire Capacity (lbs): 2335
• Rear Tire Capacity (lbs): 2150
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.5
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 24.0
• Steering Ratio (:1), At Lock: 3.14
• Turning Diameter - Curb to Curb (ft): 51.9
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 27
• Aux Fuel Tank Capacity, Approx (gal): 23
• Fuel Tank Location: Inboard LH Frame
• Aux Fuel Tank Location: Rear
• Exterior Dimensions
• Wheelbase (in): 161.5
• Length, Overall w/o rear bumper (in): 249.5
• Width, Max w/o mirrors (in): 86.0
• Height, Overall (in): 76.0
• Overhang, Front (in): 37.0
• Overhang, Rear w/o bumper (in): 51.0
• Front Bumper to Back of Cab (in): 138.1
• Cab to Axle (in): 60.4
• Cab to End of Frame (in): 111.4
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): - TBD -
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 41.1
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.7
• Front Hip Room (in): 61.5
• Second Head Room (in): 38.4
• Second Leg Room (in): 38.4
• Second Shoulder Room (in): 66.4
• Second Hip Room (in): 61.5
• Summary
• Vehicle Name: Chevrolet Silverado 3500
• Body Style: Ext Cab 161.5" Wheelbase
• Body Code: ZW9
